Product Details

Features of genset powered by Korman:

  1. International Warranty Service & Parts Depot
  2. Short delivery time, as we always have Korman engine in stock
  3. With ISO9001&14001 certification
  4. Spare parts are easy to get from worldwide market with more competitive price.
  5. Coupled with E&G, Stamford, Meccalte, Leroysomer alternator.
  6. Perfect after-service network
  7. Both 50Hz and 60Hz
  8. Rigorous test including 50% load, 75% load, 100% load and 110% load
  9. Power range from 10kVA to 3000kVA

Standard configuration of Korman open type:

  1. Korman engine
  2. E&G alternator (Stamford, Mecc alte, Leroysomer brand for option)
  3. Deepsea DSE3110 control panel as standard, AMF Control Panel Deepsea DSE7320 & Smartgen HGM6120 for Option, ATS for Option
  4. LS breaker as standard, ABB, Schneider,Chint Breaker for Option
  5. 8 Working Hours Base Fuel Tank （for the genset ≤ 650kVA prime, only Base Frame for other models)
  6. Anti-Vibration Mounted System
  7. Battery and battery switch
  8. Industrial silencer and flexible exhaust hose
Genset Model Genset Standby Power Genset Prime Power Amps Brand New Korman Engine
KVA KWe KVA KWe ESP@380V Engine Model
EG-KM 10F 11 9 10 8 33 3KMY-15
EG-KM 14F 15 12 14 11 33 4KMY-18
EG-KM 16F 18 14 16 13 42 4KMY-20
EG-KM 21F 23 18 21 17 42 4KMY-30
EG-KM 24F 26 21 24 19 50 4KMY-35
EG-KM 31F 34 27 31 25 50 4KMY-40
EG-KM 37F 40 32 37 30 67 4KMY-48
EG-KM 50F 55 44 50 40 67 4KMY-60
EG-KM 56F 62 50 56 45 92 4KMD-75
EG-KM 88F 95 76 88 70 125 4KMD-110
EG-KM 95F 105 84 95 76 167 6KMD-115
EG-KM 110F 120 96 110 88 167 6KMD-140
EG-KM 120F 130 104 120 96 201 6KMD-150
EG-KM 150F 160 128 150 120 226 6KMD-180
EG-KM 200F 220 176 200 160 251 6KMD-235
EG-KM 240F 270 216 240 192 301 6KMD-275
EG-KM 260F 290 232 260 208 301 6KMD-310
EG-KM 315F 347 278 315 252 334 6KMD-358
EG-KM 380F 420 336 380 304 418 6KMD-430
EG-KM 410F 455 364 410 328 418 6KMD-455
EG-KM 458F 506 405 458 366 526 6KMD-510
EG-KM 375F 400 320 375 300 652 8KMV-415
EG-KM 400F 450 360 400 320 735 8KMV-455
EG-KM 450F 500 400 450 360 752 8KMV-505
EG-KM 500F 550 440 500 400 836 8KMV-530
EG-KM 563F 625 500 563 450 602 12KMV-645
EG-KM 625F 680 550 625 500 669 12KMV-695
EG-KM 700F 788 630 700 560 752 12KMV-790
EG-KM 750F 825 660 750 600 1253 12KMV-825
EG-KM 800F 880 704 800 640 1337 16KMV-880
EG-KM 900F 1000 800 900 720 1519 16KMV-995
EG-KM 1000F 1100 880 1000 800 1671 16KMV-1090
EG-KM 1025F 1125 900 1025 820 1709 16KMV-1160
EG-KM 1250F 1400 1120 1250 1000 2127 12KMG-1390
EG-KM 1500F 1650 1320 1500 1200 2507 12KMG-1665
EG-KM 1700F 1875 1500 1700 1360 2849 12KMG-1870
EG-KM 2000F 2200 1760 2000 1600 3343 16KMG-2220
EG-KM 2250F 2500 2000 2250 1800 3798 16KMG-2500
EG-KM 2500F 2750 2200 2500 2000 4178 20KMG-2785
EG-KM 2750F 3025 2420 2750 2200 4596 20KMG-3050
EG-KM 3000F 3300 2640 3000 2400 5014 20KMG-3330
Genset Model Genset Standby Power Genset Prime Power Amps Brand New Korman Engine
KVA KWe KVA KWe ESP@416V Engine Model
EG-KM 11S 13 11 12 10 33 3KMY-15
EG-KM 14S 18 14 16 13 33 4KMY-18
EG-KM 16S 20 16 18 15 42 4KMY-20
EG-KM 21S 26 21 25 20 42 4KMY-30
EG-KM 25S 31 25 28 23 50 4KMY-35
EG-KM 32S 40 32 36 29 50 4KMY-40
EG-KM 37S 46 37 41 33 67 4KMY-48
EG-KM 48S 60 48 55 44 67 4KMY-60
EG-KM 57S 71 57 65 52 92 4KMD-75
EG-KM 78S 98 78 90 72 125 4KMD-110
EG-KM 85S 106 85 98 78 167 6KMD-115
EG-KM 96S 120 96 113 90 167 6KMD-140
EG-KM 105S 131 105 125 100 201 6KMD-150
EG-KM 133S 166 133 156 125 226 6KMD-180
EG-KM 182S 228 182 206 165 251 6KMD-235
EG-KM 230S 288 230 263 210 301 6KMD-275
EG-KM 255S 319 255 288 230 301 6KMD-310
EG-KM 300S 375 300 338 270 334 6KMD-358
EG-KM 335S 419 335 381 305 418 6KMD-430
EG-KM 365S 456 365 413 330 418 6KMD-455
EG-KM 459S 574 459 509 407 526 6KMD-510
EG-KM 350S 438 350 400 320 652 8KMV-415
EG-KM 400S 500 400 438 350 735 8KMV-455
EG-KM 420S 525 420 475 380 752 8KMV-505
EG-KM 450S 563 450 513 410 836 8KMV-530
EG-KM 540S 675 540 606 485 602 12KMV-645
EG-KM 600S 750 600 681 545 669 12KMV-695
EG-KM 700S 875 700 794 635 752 12KMV-790
EG-KM 750S 938 750 850 680 1424 12KMV-825
EG-KM 780S 975 780 875 700 1481 16KMV-880
EG-KM 870S 1088 870 988 790 1652 16KMV-995
EG-KM 920S 1150 920 1044 835 1747 16KMV-1090
EG-KM 1000S 1250 1000 1100 880 1899 16KMV-1160
EG-KM 1320S 1650 1320 1500 1200 2507 12KMG-1390
EG-KM 1500S 1875 1500 1688 1350 2849 12KMG-1665
EG-KM 1650S 2063 1650 1875 1500 3134 12KMG-1870
EG-KM 2000S 2500 2000 2250 1800 3798 16KMG-2220
EG-KM 2200S 2750 2200 2500 2000 4178 16KMG-2500
